Two piece floating type ball valve, Anti-static design, RTFE seat

A floating ball valve is a valve with its ball floating (not fixed by a trunnion) inside the valve body; it drifts toward to the downstream side and tightly pushes against the seat under the medium pressure to ensure a reliable seal. The floating ball valve is a simple design with good sealing performance relying on the seat material to withstand the workload as the sealing pressure is barred by the seat ring. Floating ball valves are mainly used in low to mid level pressure applications.

Kelite steel ball valves are designed manufactured to provide maximum service life and dependability. All ball valves are full ported and meet the design requirements of American Petroleum Institute Standard API 608&API 6D British standard BS 5351 and generally conform to American Society of Mechanical engineers standard ASME B16.34 valves are available in a complete range of body/bonnet materials and trims. Standard body/bonnet materials include nine grades of carbon, low alloy and stainless steel, for special applications they can be supplied in other grades of alloy and stainless steel. There's a full range of trim materials to match any service optional packing and gasket materials are available for a full range of service conditions.

• Operation

Extended lever for easy operation. Also available with gearing, motor actuators, pneumatic or hydraulic actuators for more difficult services

• Body & Bonnet

Split or 3-piece,split body& bonnet for 12" & small. Disassembles easily for repair or replacement of internal components.

• BORE

Full bore or reduced bore. Full-bore design provides exceptional flow control.

• End Connections

A choice of flanged RTJ flanged or buttwelding end for piping flexibility. E)Packing
Std packing multiple v-teflon packing, combined with live loading,maintains packing compression under high-cycle and severe service applications.

• Blow-out proof stem design

Blow-out proof stem, a pressure-safe stem shoulder design that protects against failure under excess pressure.

• Anti statics design

Anti statics. A metallic contact is always granted between ball and stem /body to discharge eventual statics build-up during service. H)FS
Fire safe designed to API607 or BS 6755 to grant their operation suitability in case of fire. Secondary metal-to metal seal acts as backup if primary seal is destroyed by fire. Valves ordered for compliance with API 607 will be provided with graphite packingand gaskets.

Kelite Valve is a leading manufacturer of quality valve products including cast steel, and forged steel Ball, Gate, Globe, Check, Butterfly and Plug valves. Our diverse product line is utilized in virtually all industries including Power, Chemical, Petrochemical, Oil and Gas,Pulp and Paper.

Designed and engineered to the highest possible standards, our valve range is found in a substantial array of applications in almost all industries; from Petrochemical, Oil and Gas, Chemical, to power generation, Pulp and Paper.

Accredited worldwide by respected companies for over two decades, your valve requirements translates into our commitment of offering a quality product line at competitive prices. Kelite Group and its experienced team will meet, and exceed your expectations.

"Constantly pursue and innovate" is the spirit of the Kelite Group, “AlI consideration for the customers" is the marketing purpose of Kelite Group, We would like to provide more and more products with better quality and service, so as to meet the different requirements of our customers. We hope that more and more customers choose to use our products. Look forward to cooperating with your esteemed company in the near future.
