Electric Cast Globe Valve / Stainless Steel Globe Valve Customized Size

    Buy cheap Electric Cast Globe Valve / Stainless Steel Globe Valve Customized Size from wholesalers

    Buy cheap Electric Cast Globe Valve / Stainless Steel Globe Valve Customized Size from wholesalers
    • Buy cheap Electric Cast Globe Valve / Stainless Steel Globe Valve Customized Size from wholesalers

    Electric Cast Globe Valve / Stainless Steel Globe Valve Customized Size

    Ask Lasest Price
    Brand Name : Kelite Valve
    Model Number : 2"-24", CL150-1500
    Certification : API, ISO, CE, GOST, TS, BS1873, BS5351, API 6D,600,602,609, ASME B16.34, API 6FA, API607 etc
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 3000-5000PCS per month
    Delivery Time : 30-60days
    • Product Details
    • Company Profile

    Electric Cast Globe Valve / Stainless Steel Globe Valve Customized Size

    2"-24" CL150-1500 bolted bonnet cast globe valve, OS&Y, rising stem


    Size:NPS 2"~24"
    Pressure Rating:Class 150~1500
    Material:CF8M, CF3,CF3M, CN7M, CF8CWCB, LCB, WC6, WC9, C12, C5, CF8, CF8M, CF3, CF3M
    Design & Manufacturing Standard:BS 1873 ,ASME B16.34
    Face to Face:ASME B16.10
    Flanged Dimenson:ASME B16.5, ASME B16.47, BSEN 1092
    End Connection:ASME B16.25BSEN 558, ASME B16.5 ,BSEN 1092
    Test and Inspection:ISO 5208,BS 6755
    Structure type:Straight type, angle type, throttle type
    Operation Method:Manual ,Worm Gear, Electric Actuator,
    Pneumatic Actuator

    Design

    Kelite cast steel globe valves are designed and manufactured to provide maximum service life and dependability. All globe valve are full ported and meet the design requirements of American Petroleum Institute standard API600& 6D.BS EN 13709 and generally conform to American Society of Mechanical Engineers standard ASME B16.34 .Valves are available in a complete range of body/bonnet materials and trims.

    Ranges of Materials

    Standard body/bonnet materials include nine grades of carbon, low alloy and stainless steel, for special applications they can be supplied in other grades of alloy and stainless steel, there’s a full range of trim materials to match any service optional packing and gasket materials are available for a full range of service conditions.


    Available Modifications For Kelite Steel Valves

    Trim changes
    End connection modifications
    Packing and gasket changes
    Operator mounting
    Handwheel extensions
    Pressure equalizing
    By-pass
    Customer specified coatings
    Weld end bore changes
    Oxygen & chlorine cleaning & packaging
